iCharger 4010Duo
4010DUO
High-power charger providing 40 amps on each of two channels - or combine the two outputs in parallel for up to 70 amp charge rates!
Includes a free JST-XH balance board for each channel!
Includes a free JST-XH balance board for each channel!
There's a new heavyweight in the ring: the iCharger 4010Duo. With two channels available, each of which can charge at up to 40 amps simultaneously, it's like having two superchargers in one. Or combine both channels in parallel to achieve up to 70 amp charge rates!
With two JST-XH balance boards thrown in for free - one for each channel - you'll be ready to go right away.
With two JST-XH balance boards thrown in for free - one for each channel - you'll be ready to go right away.
Read More
| Input Voltage | 9 - 50V DC |
| Dimensions | 210x140x80 mm |
| Balance Accuracy | 10mV |
| Memories | 64 user presets |
| Current Drain (Balancing) | 1.2A per channel (up to 2.4A in synchronous mode) |
| Discharge Current Range | 0.05-40A per channel (up to 70A in synchronous mode) |
| Input Current | 65A |
| Temperature Control (Intel.) | Yes |
| LiPo/LiIo/LiFe | 1 - 10 series |
| Charge Power (Max) | 2000W at >34V (1400W max. per channel) |
| Discharge (Max) | 130W per channel (up to 200W in synchronous mode) |
| External Discharge (Max) | 1600W per channel (up to 3200W in synchronous mode) |
| Regenerative Discharge (Max) | 1400W per channel (up to 2000W in synchronous mode) |
| Cell Count (NiCd/NiMh) | 1 - 25 series |
| Pb Battery Cell Count | 1 - 18 series |
| PC Connectivity | Mini USB 2.0 |
| Warranty | 1 year |
| Weight | 1470g |
| Charge Current Range | 0.05-40A per channel (up to 70A in synchronous mode) |
iCharger 4010Duo Manual
